LE24M Series Monocrystalline solar panel are more efficient compare to polycrystalline solar panel based on utilization of pure silicon crystal material. During converting sunlight toward to energy, this factor of purity enhance the panel output more effective. LE24M series increase the efficiency along with maintaining the cost, silicon crystal cells are cut from the corner edges for productive efficiency. LE24M series consume least area space to installation comparative to Polycrystalline.
| Model Type | LE24M335 | LE24M340 | LE24M345 | LE24M350 | LE24M350 | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| STC | NOCT | STC | NOCT | STC | NOCT | STC | NOCT | STC | NOCT | |
| Power Output Pmax (W) | 335 | 249.91 | 340 | 253.64 | 345 | 257.37 | 350 | 261.1 | 355 | 264.83 |
| Voltage at Pmax V mpp (V) | 38.47 | 35.93 | 38.73 | 36.17 | 38.92 | 36.35 | 39.04 | 36.46 | 39.31 | 36.72 |
| Current at Pmax I mpp (I) | 8.73 | 6.96 | 8.78 | 7.01 | 8.87 | 7.08 | 8.97 | 7.16 | 9.04 | 7.21 |
| Open-circuit Voltage VOC (V) | 45.64 | 42.9 | 45.76 | 43.01 | 45.91 | 43.16 | 46.02 | 43.26 | 46.44 | 43.65 |
| Short-circuit Current ISC (I) | 9.18 | 7.37 | 9.27 | 7.44 | 9.35 | 7.51 | 9.48 | 7.61 | 9.54 | 7.66 |
| Module Efficiency % (%) | 17.23 | 17.49 | 17.75 | 18.01 | 18.26 | |||||
90% of the specified minimum output of the module for a 10 years period. 80% of the specified minimum output of the module for a 25 years period. 10-year product warranty. 25-year linear performance warranty.
| Dimensions (L / W / H) | : 1961mm / 991mm / 35mm |
| Weight | : 21.5kg |
| Front Cover (material / thickness) | : AR coated high transmission low iron tempered glass / 3.2 mm |
| Cell (qty. / material / dim./no. of busbars) | : 72 / Monocrystalline Silicon/ 156.75mm x 156.75mm / 5B B |
| Encapsulate (material) | : Ethylene vinyl acetate (EVA) |
| Backsheet | : UV Protected |
| Frame (material / color ) | : Anodized aluminum alloy / silver |
| Junction Box (protection degree) | : IP6 8, 3 bypass diodes |
| Cable (length / cross-sectional area | : 1200mm / 4mm2 |
| Plug Connector ( type / protection degree) | : MC4 / IP68 |
| Nominal Operating Cell Temperature | : 46+/-2 |
| Temperature Coefficient of Pmax | : -0.350 |
| Temperature Coefficient of VOC | : -0.301 |
| Temperature Coefficient of ISC | : 0.05 |
| Max. System Voltage | : 1500Vdc |
| Max. Series Fuse Rating | : 15A |
| Limiting Reverse Current | : 20A |
| Operating Temperature Range | : -40°c to 85°c |
| Max. Static Load, Front | : 5400Pa |
| Max. Static Load, Back (e.g., wind) | : 2400Pa |
| Max. Hailstone Impact (diameter / velocity) | : 25mm / 23.3 m /s |
| Number of Modules Per Pallet | : 30 |
| Number of Pallets per 40' Container | : 24 |
| Packaging Box Dimensions (L / W / H) | : 2005mm / 1115mm / 1150mm |
| Box Weight | : 700kg |
